Dimensions

Load Ratings

Weight

Sliding
Contact
Surfaces

Relubrication
Needed

Integral
Seals

d

d₁

B

C

D

d_k

m

α

COM 3

4.826

7.44

7.14

5.54

14.29

10.31

0.381

11

14.464

0.006

Steel/Steel

Yes

No

COM 4

6.35

9.25

8.71

6.35

16.67

12.7

0.56

13.5

22.015

0.01

Steel/Steel

Yes

No

COM 5

7.938

10.64

9.53

7.14

19.05

14.27

0.81

12

28.8

0.014

Steel/Steel

Yes

No

COM 6

9.525

13.11

10.31

7.92

20.64

16.66

0.81

10

37.361

0.017

Steel/Steel

Yes

No

COM 7

11.113

13.46

11.1

8.71

23.02

17.45

0.81

8

42.048

0.021

Steel/Steel

Yes

No

COM 8

12.7

16.26

12.7

9.91

25.4

20.65

0.81

9.5

58.934

0.029

Steel/Steel

Yes

No

COM 9

14.288

18.03

14.27

11.1

27.78

23.01

0.81

9.5

73.967

0.039

Steel/Steel

Yes

No

COM 10

15.875

19.81

15.88

12.7

30.16

25.4

0.81

8.5

94.658

0.5

Steel/Steel

Yes

No

COM 12

19.05

23.37

19.05

15.06

36.51

30.15

1.12

9

141.982

0.093

Steel/Steel

Yes

No

COM 14

22.225

24.89

22.23

17.86

39.69

33.32

1.12

9.5

186.639

0.119

Steel/Steel

Yes

No

COM 16

25.4

28.4

25.4

20.24

44.45

38.1

1.12

10

245.534

0.175

Steel/Steel

Yes

No

HCOM 16

25.4

34.54

25.4

19.84

50.8

42.85

0.81

9

315.01

0.251

Steel/Steel

Yes

No

HCOM 19

30.163

40.89

30.15

23.8

60.33

50.8

0.81

8.5

448.049

0.406

Steel/Steel

Yes

No

HCOM 20

31.75

40.89

30.15

23.8

60.33

50.8

0.81

8.5

448.049

0.406

Steel/Steel

Yes

No

HCOM 24

38.1

47.24

34.93

27.79

69.85

58.72

0.81

8.5

604.71

0.616

Steel/Steel

Yes

No

HCOM 28

44.45

53.59

39.67

31.75

79.38

66.68

1.12

8

784.495

0.884

Steel/Steel

Yes

No

HCOM 32

50.8

59.94

44.45

34.93

88.9

74.6

1.12

8.5

965.485

1.198

Steel/Steel

Yes

No
